Easy to call standard values, which simplifies testing
It is equipped with a mode for determining CW/CCW and measuring the magnetic flux distribution.
There is no adjustment required for each model, and it can be tested only by the initial setting.
| Power suply | AC90V-240V 50/60Hz | |
| Excitation Signal | Phase | Three Phase |
| Frequency | 5kHz （Sine wave） | |
| Excitation voltage | Phase 5Vp-p | |
| Setting range | 100 steps | |
| Detection | Sensitivity Range | 10 steps＋Auto setting range mode |
| Corresponding poles | 2/4極（Normal diecotor）
2/4/6/8極（Option ditector） |
|
| Outer diameter of ditector | 2/4 pole(Normal type）：Φ38mm
2/4 pole（Option type）：Φ22mm 2/4/6/8 pole（Option type）Φ45mm |
|
| General | Environment | Temperature range5℃-40℃ Humid range20%-80% |
| Dimensions/Weights | H98×W195×D350 (mm)/1.8kg | |
| Power consumption | 40VA以下 | |
| Communication | I/O、RS232C | |
| Accessories | Power cable (3m) 1 unit
3P-2P conversion adapter 1 unit Diteotor Cable（1.5m) 1 unit Excitation signal cable (1.5m) 1 unit Normal Ditector Coil 1 unit Manual 1unit Spare Fuse（1A） 1unit |
|
■Specification and a design may be changed without a preliminary announcement for improvement reasons etc.
■There may be difference in a color, textures, etc. may be on the photograph which are written on the catalog during printing.
■Although an effort is made to indicate exact information about the contents of this catalog, if there should be a point of advice , such as a clerical error, please give a notice to sales promotion division of our company.
► We also have calibration certificate attached ( optional )
► Please re-calibrate after use for a certain period through our purchase store.
